A new, safer appliance, the limit switch

Advantages of limit switch

1, no matter what kind of material, as long as the contact operating force reaches a certain value, you can touch the switch and connect the power supply.

2, the contact output mode can be different with the external voltage and the output is different, there will be no leakage phenomenon.

3, will not be affected by adjacent sensors, the output is stable.

The use of limit switches in life will be less, generally it will be used in large-scale industrial production, or life appliances. Therefore, our understanding of it is relatively weak, the above to give you a summary of its classification and advantages, after reading will have a certain understanding. Although such electrical appliances are less used in our personal lives, they are also closely related to our lives, and everyone needs a certain amount of daily life knowledge accumulation!

The working principle and classification of switches

The limit switch is an electrical switch that limits the motion limit position of the mechanical equipment. It can be divided into two main types, contact and non-contact. The contact switch is more intuitive, and the upper stroke switch is installed on the moving parts of the mechanical equipment. A stop is installed in the limit position with respect to the fixed point of relative motion, or in the opposite position. When the mechanical contact of the travel switch touches the stop block, it will cut off or control the circuit, so that the machine will stop running or change the operation. But the machine has inertial motion, so this travel has a certain "overtravel" to protect the switch from wear. There are various forms of non-contact switch, common photoelectric type, induction type and so on. In general, these forms are often seen in elevators, and there are more advanced forms.

The limit switch is mainly composed of a switching element, a switching actuator and a transmission part, which can be divided into the following according to the mechanical principle of switching contacts.

The switching time of the switch on and off action is related to the switching frequency, and the faster the frequency, the faster the switching is. The switching time of switching on and off has nothing to do with the switching frequency. As long as the switch is operated to a certain position, the switch will be connected and disconnected, and a certain operating process time is required in the middle.
